Maxon Datamax 4G User Manual

Antenna Installation
Attach the cellular antenna (with SMA male connector) into the female SMA
interface on the router labelled “ANT”.
Attach the WIFI antenna (with SMA female connector) into the male SMA
interface on the router labelled “WIFI”.
RS232 Interface
The router supports an RS232 interface that utilises an RJ45 connector and is
labelled as “Console” on the router.
If required, plug the RJ45 end of the serial cable into the RS232 port on the router
and plug the DB9F end of the serial cable into the serial interface of the user’s
device.
The pin connections of the RJ45-DB9F serial cable are as follows:
RJ45
DB9F
1
8
2
6
3
2
4
1
5
5
6
3
7
4
8
7
The signal definition of the DB9F serial communication interface is as follows:
Pin
RS232 signal
Direction
1
DCD
Output
2
RXD
Output
3
TXD
Input
4
DTR
Input
5
GND
6
DSR
output
