Maxon GPSLR Series - Hydraulic Schematic - Gravity down

11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
72
FIG. 72-1
HYDRAULIC SCHEMATIC - GRAVITY DOWN
NOTE: PRV (PRESSURE RELIEF VALVE)
PRV
1800 PSI
PUMP
PUMP
FILTERFILTER
AUX, PUMP
ASSEMBLY
PRV
2750 PSI
FLOW
CONTROL
VALVE (3 GPM)
HYDRAULIC
LOCK VALVE
(BI-DIRECTIONAL)
C1 OUTLET
PORT
C2 OUTLET
PORT
RH CYLINDERLH CYLINDER
TANK
RETURN
HYDRAULIC
MOTOR
HYDRAULIC
LOCK VALVE
(BI-DIRECTIONAL)
S1
S3
S2 S2
G1
G
M
HYDRAULIC
LOCK VALVE
(BI-DIRECTIONAL)
SYSTEM DIAGRAMS - Continued
DRAFT 05-03-24
