Maxon GPSLR Series - Pre-Delivery Inspection Form

11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
83
Pre-Installation Inspection:
Correct model Correct capacity
Correct platform size Correct options
Manuals & decals
Structural Inspection:
Inspect alignment of fi nal assembly.
Inspect pump box secure mounting.
Inspect all installation welds.
Check roll pins, bolts and fasteners.
Inspect tightness of hardware used to secure
liftgate to vehicle.
Ensure platform ramp touches ground when
shackles are 1” above ground, and platform &
fl ipover are level & touching the ground.
Hydraulic Inspection:
Proper fl uid level (See CHECKING
HYDRAULIC FLUID step in this manual).
Check hydraulic fi ttings in pump box for leaks.
Check hydraulic line connections for leaks.
Electrical Inspection:
Check power/charge plug and terminal.
Check for tight wire connections.
Circuit breaker (150A) installed in battery box
(if equipped) or by truck/tractor battery.
Ensure batteries are fully charged, all cable
connections are tight & protected from
corrosion and tiedowns are tight.
Inspect all solenoid connections.
Check all wiring harness connections.
Check electrical cable connections are tight,
secure, and protected from corrosion.
Model:______________________ Date: ____________________
Serial Number: _______________ Technician: _______________
Operation Inspection:
Check operation of all main and optional
control switches.
GPSLR-35
Unloaded platform lowers in 10 sec.
Unloaded platform raises in 14 sec.
Unloaded platform stows IN in 9-10 sec.
Unloaded platform to OUT position in 6-7 sec.
GPSLR-44
Unloaded platform lowers in 7 to 11 sec.
Unloaded platform raises in 9 to 13 sec.
Unloaded platform stows IN in 12 sec.
Unloaded platform to OUT position in 8 sec.
GPSLR-55
Unloaded platform lowers in 14 sec.
Unloaded platform raises in 14 sec.
Unloaded platform to stow position in 9-10 sec.
Unloaded platform to OUT position in 6-7 sec.
All GPSLR: Unloaded platform raises and
lowers evenly. At the extension plate, platform
must not be more than 1/8” uneven, from side
to side.
All GPSLR: Platform stores securely under
vehicle body.
Check if cycle counter works.
Decals in correct location and legible.
Verify all lights are operational
Platform lights turn ON when platform is un-
folded, and turn OFF when platform is stowed.
Taillights, stop lights, turn lights, and backup
lights turn ON and OFF correctly.
NOTE: The following times are for 60” bed
height, steel platform with aluminum
fl ipover, Exxon Univis HVI-13 hydrau-
lic fl uid, & temperature at 70°F. Times
are for reference only and may vary
for larger platforms, smaller platforms,
or temperature changes.
PRE-DELIVERY INSPECTION FORM
DRAFT 05-03-24
