Configuring Drives (Dual Drive Units Only) 85

Maxtor Central Axis Admin User Guide

Step 8: Set the failed disk drive aside and position the replacement disk drive as shown

below:

Figure 129: Mounting Brackets

Figure 130: Mounting Bracket Fasteners (two on each side)
