L3 Turbo Engine
Camshaft Sprocket
• The sintered alloy, which has high rigidity, has been adopted for the camshaft sprocket
and is quenched to improve the abrasion resistance at the contact point with the timing
chain.
• The intake camshaft sprocket is integrated with the variable valve timing actuator and
must not be disassembled.
M6-MPS01016
1 Camshaft sprocket 2 Variable valve timing actuator
01-14 Service Training Mazda6 MPS Supplement
