L3 Turbo Engine
Lubrication System Flow Diagram
M6-MPS_01019
1 OCV 13 Orifice
2 Variable valve timing actuator 14 Timing chain
3 Tappet 15 Chain tensioner
4 Camshaft 16 Piston
5 Turbocharger 17 Oil jet valve
6 Balancer shaft 18 Main Bearing
7 Oil pan 19 Crankshaft
8 Oil strainer 20 Connecting rod bearing
9 Oil pump 21 Oil passage
10 Oil cooler 22 Oil relief passage
11 Oil filter 23 Oil bypass passage
12 Oil pressure switch
01-18 Service Training Mazda6 MPS Supplement
