Driveline/Axle
Transfer Case Oil Level Inspection
M6-MPS_03011
Adjustment Procedures Necessary For Transfer Case Assembly
– drive gear shaft axial play and preload (adjustment shim)
– ring gear shaft axial play and preload (left and right adjustment shims)
– drive pinion height and preload (spacer)
– drive pinion backlash (sliding the ring gear in shaft direction by varying the
thicknesses of the left and right adjustment shims while maintaining total thickness of
both)
– drive pinion and ring gear tooth contact (drive pinion height and backlash by spacers)
• For the detailed procedures please refer to the current Workshop Manual.
Service Training Mazda6 MPS Supplement 03-7
