Driveline/Axle
Transfer Case Oil Cooler
M6-MPS_03007
1 Water in 2 Water out
Transfer Case Oil
• The transfer case is filled with 1.2 litre transmission oil. The transmission oil must comply
with SAE 80 or SAE 90 (API service GL-5) specification.
• The transfer case is filled with oil for lifetime and there is generally no need for
replacement or a level check during scheduled maintenance. Nevertheless, if there are
traces of oil leaks a level check is recommended. If the transfer case has been
submerged in water, the oil must be changed.
M6-MPS_03010
1
Drain plug
03-6 Service Training Mazda6 MPS Supplement
