Refer to Lane Departure Warning System
(LDWS) on page 4-96.
Mazda Radar Cruise Control (MRCC)
display (Type A instrument cluster)
í
Information regarding the Mazda Radar
Cruise Control (MRCC) is displayed.
Refer to Mazda Radar Cruise Control
(MRCC) on page 4-116.
Distance Recognition Support System
(DRSS) display (Type A instrument
cluster)
í
Information regarding the Distance
Recognition Support Sy stem (DRSS) is
displayed.
Refer to Distance Recognition Support
System (DRSS) on page 4-108.
Warning (Display Indication) (Type A
instrument cluster)
A message is displayed to notify the user
of the system operation status and
malfunctions or abnormalities.
Check the indicated message.
When Driving
Instrument Cluster and Display
4-19
í
Some models.
