Constant Monitoring
The following components of the air bag systems are monitored by a diagnostic system:
l
Crash sensors, and diagnostic module (SAS unit)
l
Front air bag sensors
l
Air bag modules
l
Side crash sensors
l
Air bag/Front seat belt prete nsioner system warning light
l
Front seat belt pretensioners
l
Related wiring
(With Front Passenger Occupant Classification System)
l
Front passenger air bag deactivation indicator light
l
Front passenger occupant classification sensor
l
Front passenger occupant classification control module
The diagnostic module continuously monitors the system's readiness. This begins when the
ignition is switched ON and continues while the vehicle is being driven.
2-66
Essential Safety Equipment
SRS Air Bags
