qWhen the System Operates
1. The system goes on operation standby
when the LDWS switch is pressed and
the LDWS OFF indication/indicat or
light turns off.
On the type A instrument cluster, the lane
indication (border line) is indicated in the
multi-information display.
Indication on display
2. Drive the vehicle in the center of the
driving lane while the LDWS OFF
indicator light is turned off. The system
becomes operational when all of the
following conditions are met.
l
The vehicl e is driven in the center of
the driving lane with the white or
yellow lines on the left and right sides,
or on either side.
l
The vehicl e speed is 65 km/h (41 mph)
or faster.
l
The vehicl e is driven on a straight road
or road with gentle curves.
On the type A instrument cluster, the lane
indication is indicated in the multi-
information display.
Indication on display
The LDWS does not operate in the
following cases:
l
The system cannot detect white or
yellow lines.
l
The vehicl e speed is less than 60 km/h
(37 mph) .
l
The vehicl e is making a sharp curve.
l
The vehicl e is making a curve at an
inadequate speed.
When Driving
i-ACTIVSENSE
4-99
