Signal Warning/Indicator Lights Page
Check Fuel Cap Warning Indication 4-35
Seat Belt Warning Light 4-35
Door-Ajar Warning Indication 4-36
Liftgate-Ajar Warning Indication 4-37
Low Washer Fluid Level Warning Indication 4-37
Tire Pressure Monitoring System Warning Light 4-37
KEY Warning Indication 4-39
High Beam Control System (HBC) Warning Light (Amber)/Indicator Light
(Green)
4-41
Wrench Indication 4-41
TCS/DSC Indicator Light 4-41
TCS OFF Indicator Light 4-42
Smart Brake Support/Smart City Brake Support (SBS/SCBS) OFF Indicator
Light
4-42
Smart City Brake Support (SCBS) Warning Indication 4-42
Low Engine Coolant Temperature Indicator Light (Blue) 4-42
When Driving
