Black plate (159,1)
Signal Warning/Indicator Lights Page
Master Warning Light 4-27
Brake System Warning Light 4-27
ABS Warning Light 4-28
Electric Parking Brake Warning Light 4-29
Brake Pedal Operation demand Indicator Light 4-29
Charging System Warning Light 4-29
Engine Oil Warning Light 4-30
Check Engine Light 4-30
High Engine Coolant Temperature Warning Light (Red) 4-31
Lane Departure Warning System (LDWS) Warning Light 4-31
Lane Departure Warning System (LDWS) OFF Indicator Light 4-32
AWD Warning Light 4-32
Automatic Transaxle Warning Light 4-33
Power Steering Malfunction Indicator Light 4-33
Air Bag/Front Seat Belt Pretensioner System Warning Light 4-34
Low Fuel Warning Light 4-35
When Driving
Instrument Cluster and Display
4-25
CX-5_8DV2-EA-14K_Edition5 Page159
Tuesday, November 24 2015 8:47 AM
Form No.8DV2-EA-14K
