72
Inner Wing Shaft (3)
Figure 5.7 – Inner/Outer Wing Shaft Grease Locations
Quantit
y of Pumps
Model PTO Input Speed
(Shaft Siz
e
)
(C) - Cross (S) – Shield
Bearings
(T) – Telescopic
Members
SR
620
1000 (S6) 13 6 20
SR
820
1000 (S8) 22 6 32
Table 5.7 – Inner Wing Shaft Grease Quantities
Outer Wing Shaft (4)
Refer to Figure 5.7 for reference to grease points
Quantity of Pumps
Model PTO Input Speed
(Sh
aft Size)
(C) - Cross (S) – Shield
Bea
rings
(T) – Telescopic
Me
mber
s
SR
460
540/1000 (S6) 13 6 20
SR
620
1000 (S6) 13 6 20
SR
820
1000 (S6) 13 6 20
Table 5.8 – Outer Wing Shaft Grease Quantities
