Extrium DT42 Ports Description
Ethernet
Used for web configuration access and sending TCP alarm events to STReceiver or TcpToCom.
Used also for IP reception.
Serial input
Serial input can be used to plug an external receiver.
Multiple input format are supported: MCDI, SURGARD MLR2, ADEMCO, SILENT KNIGHT.
USB to PC port
USB output port.
It is used to send alarm event to PC over USB.
USB device ports
You can connect USB compatible receiver on this port, or use a USB-to-serial cable to pug a serial receiver.
CPU reset
Use this button to reset/reboot the whole unit:
- 1 Second will reset the unit
- 8 Second will force halt
Micro-SD Card
Micro-SD card memory slot.
NOTE: If you want to change the micro-SD, power the unit down
NOTE2: micro-SD card capacity limit accepted by Extrium DT42 is 32GB
