2 - 7
Overview
Electrical Box
The main power switch is located on the outside of the electrical
box. Next to the power switch is a digital volt meter. This meter
shows the incoming voltage to the unit. Located on the side of
the electrical box is an hour meter that indicates how many hours
the unit has been in operation. Also included is a motor circuit
breaker.
TX00470-9-15-94
Pipe Lifts
Pipe lifts are provided to assist in pipe handling. The pipe lifts
can be secured using detent pins during machine transport or
movement of pipe.
TX00469-9-15-94
Insulated Heater Stand
The heater should always be stored in the insulated heater stand
or blanket for protection of the operator and to minimize heat loss
and risk of mechanical damage.
TX00363-9-15-94
Heater Adapters
Heaters and heater adapters are available for saddle fusion of
tapping tees, stopple fittings, and branch saddles.
NOTICE: The heater should never be used without butt fusion
heater adapters installed.
TX00362-9-22-94
PH00416-11-1-94
PH02492-07-08-03PH03874-6-5-13
PH00348-9-9-94
