Raise Pipe
Raise the joined pipe using both of the pipe lifts.
TX00382-9-16-94
Position Pipe for Next Joint
Move the fusion machine to end of pipe, or pull the pipe through
the jaws until the end of the pipe is protruding 1" past the jaw
face of the fixed jaw.
TX00383-9-15-94
Butt Fusion Procedure
3 - 10
PH02492-07-08-03
PH00306-9-12-940
Install Next Piece of Pipe
Insert a new piece of pipe in movable jaws and repeat all
previous procedures.
TX00384-10-12-95
PH02497-07-08-03
