7 - 2
Maintenance
Clean Eyebolt Threads
Keep the clamp knob eyebolt threads brushed clean.
TX00435-9-13-94
Clean Jaws and Inserts
To prevent slippage and insure proper alignment, the jaws and
inserts must be clean.
Clean the jaws and inserts of any dirt or residual material using
a stiff-bristled brush.
TX00433-9-15-94
Clean Thrust Bearings
The thrust bearings located in the clamp knobs must turn freely.
Wash the clamp knob bearing assembly with a solvent, and then
lubricate with 30W or lighter oil.
TX00434-9-13-94
Check Gauge
Gauge should be checked daily.
The gauge should read zero when the unit is not running.
Damaged gauges should be replaced.
TX02291-3-8-04
PH02489-07-11-03
PH02687-7-30-04
PH00377-9-14-94
PH00377-9-14-94
