Generator Sizing Form
Complete this form and provide a copy to your generator supplier. This information will enable your generator
supplier to correctly size a generator for your application.
Motor: 1 - 1/2 Horsepower
Motor Code Letter: (from motor nameplate should be J or K)
Motor Voltage: (120 or 220 VAC)
Motor Phases: 1
Motor Frequency: ____________ (50 or 60 Hz)
Heater Wattage Rating: Watts resistive
Heater Voltage: (120 or 220 VAC)
Operational Altitude Range: __________ to __________
Ambient Temperature Range: __________ to __________
Duty Cycle: Standby (Not continuous 24 hours/day)
Allowable Voltage Dip: 20%
Allowable Frequency Dip: 5%
Starting Load Application: Simultaneous turn-on of both motor and heater.
Running Load: Motor continuous, heater cycling on and off at approximately 5 minute intervals.
Fuel: _______________ (Gasoline or Diesel)
Special requirements for customer application: ____________________________________________________________
___________________________________________________________________________________________________
___________________________________________________________________________________________________
___________________________________________________________________________________________________
___________________________________________________________________________________________________
___________________________________________________________________________________________________
___________________________________________________________________________________________________
___________________________________________________________________________________________________
TX00473-9-17-94
