Introduction
Thank you for purchasing this
McElroy product
The McElroy 28 hydraulically operated fusion machine
will butt fuse all pipe sizes from 2" IPS through 8" DIPS
(63 mm - 225 mm).
The 250 model fuses 2” IPS (63mm) minimum to 250mm
maximum pipe.
The combination unit adds saddle fusion capability of up
to an 8" DIPS outlet with up to 9 5/8" diameter base on
any size main. The machine also allows for butt fusion of
most fittings without special holders or removal of outer
jaws. Mitered inserts are also available for fabricating
ells in the shop or in the field. With reasonable care and
maintenance, this machine will give years of satisfactory
service.
Before operating this machine, please read this manual
thoroughly, and keep a copy with the machine for future
reference. This manual is to be considered part of your
machine.
TX02502-6-5-13
PH02481-07-08-03
McElroy University
For more than 30 years, McElroy has been the only
pipe fusion machine manufacturer to continuously
offer advanced training. Course offerings are meant to
enhance your efficiency, productivity and safety in the
proper use of McElroy machines. McElroy University
classes are structured so that the skills learned and the
machines used in each class closely match the machines
found on pipelining jobsites. We offer training at
our facility or yours. Our uniquely qualified McElroy
University course instructors offer years of industry
experience.
Tuition for each course includes lunches, course materials
and a certificate of completion. Online registration,
as well as up-to-date course offerings and dates, is
available at www.mcelroy.com/university
This manual is intended as a guide only and does not
take the place of proper training by qualified instructors.
The information in this manual is not all inclusive and
can not encompass all possible situations that can be
encountered during various operations.
MU2-03-13-14
TX04659-03-24-14
