Carriage Shut-off Valve
A shut-off valve is installed on the carriage. When it is closed, the
operator at the HPU can not move the carriage.
TX04048-4-12-10
Clamp Knobs
Clamp knobs are equipped with a thrust bearing, which permits
the operator to develop high clamping forces with minimal effort.
TX03099-4-12-10
PH04133-4-12-10
Overview
2 - 7
PH03895-3-29-10
CLOSED
OPEN
Stripper Bar
The heater stripper bar can be attached to the heater to assist in
separating the heater from the molten pipe. Refer to the instruction
sheet packaged with the stripper bar for assembly instructions.
TX03095-4-7-10
PH04127-4-12-10
