Position Pipe for Next Joint
Move the fusion machine to end of pipe, or pull the pipe through
the jaws until the end of the pipe is protruding .75" for 28 and
1.25" for 250/412 past the fixed jaw.
TX04015-4-12-10
Butt Fusion Procedure
3 - 14
Install Next Piece of Pipe
Move the carriage control valve and open the carriage completely.
Insert a new piece of pipe in movable jaws and repeat all
previous procedures.
TX04016-4-12-10
PH04104-3-29-10
PH04098-3-29-10
