After Facing
Move the carriage control valve to the right to open the carriage.
Release the handle lock, and lift the facer out.
Close carriage shut off valve.
Jaws are operated hydraulically by a remote operator. Anything
caught in the jaws will be crushed. Always communicate clearly
with the second operator and use the carriage shut off valve to
lock out jaw motion.
Remove chips from pipe ends.
Do not touch faced pipe ends.
Inspect both pipe ends for complete face off. If the face off is
incomplete, return to Loading Pipe into Machine.
Open shut off valve.
TX04040-4-12-10
PH04100-3-29-10
Butt Fusion Procedure
3 - 8
