Install Heater Adapters
Heater is not explosion proof. Operation of
heater in an explosive atmosphere without
necessary safety precautions will result in serious
injury and death.
If operating in an explosive atmosphere, heater should be brought
up to temperature in a safe environment, then unplugged before
entering the explosive atmosphere for fusion.
Select appropriate heater and sidewall fusion heater adapters.
Clean heater surfaces and adapter surfaces. Attach the adapters
to the heater.
Place heater in insulated heater blanket.
Plug heater into a proper power source.
TX00455-04-07-14
Saddle Fusion Procedure
The 28 Sidewall fuses branch saddles up to 8" DIPS outlet and
up to a 9-5/8" diameter base on any size main.
IMPORTANT: Optional chain extension kit is available for larger
main sizes.
TX04045-4-12-10
Special Operations
- Saddle Fusion Procedure
PH04108-3-30-10
5 - 1
PH04117-4-5-10PH04118-4-5-10
Assure Saddle Will Fit
For branch saddles, a nipple long enough to extend through
the movable jaw may need to be butt fused using a butt fusion
machine and the butt fusion procedures.
TX04022-4-12-10
PH00423-11-1-94
