7 - 2
Maintenance
Clean Jaws and Inserts
To prevent slippage and insure proper alignment, the jaws and
inserts must be clean.
Clean the jaws and inserts of any dirt or residual material using
a stiff-bristled brush.
TX00433-9-15-94
Clean Thrust Bearings
The thrust bearings located in the clamp knobs must turn freely.
Wash the clamp knob bearing assembly with a solvent, and then
lubricate with 30W or lighter oil.
TX00434-9-13-94
Check Pressure Gauges
Both pressure gauges should be checked daily.
The gauges should read zero when the unit is not
running.
Damaged gauges should be replaced.
TX04033-4-12-10
Accumulator Charge
The precharge should be checked every 6 months.
The accumulator must be charged by a qualified hydraulic service
facility to a nitrogen precharge of 500 psi.
An approximate amount of charge can be noted on the system
pressure gauge when the HPU is turned on. When the HPU is
turned on, the gauge will jump to a pressure before continuing
to build pressure. The initial jump in pressure will indicate the
approximate pressure of the precharge.
NOTICE: The precharge should be checked/maintained by a
qualified hydraulics repair tech.
TX04695-04-08-14
PH04139-4-12-10 PH05177-04-08-14PH04138-4-12-10
PH03894-3-29-10PH03895-3-29-10
