McHale V Series Baler
12
2.4 General specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
*Check with national road traffic regulations in the individual country!
2.5 Tractor specifications
Model V6740/ V8940 V6750/ V8950
Transport length 5.1 m (201”)
Transport width 2.62 m (103”)
Transport height 2.96 m (117”)
Transport weight (unladen) 4,450 kg (9,811 lbs) 4,850 kg (10,692 lbs)
Axle weight (unladen) 3,750 kg (8,267 lbs) 4,000 kg (8,819 lbs)
Maximum road speed* 40 km/h (25 mph)
Tractor capacity 60 kW (80 HP)
Hitch type High/Low drawbar
PTO speed 540 rpm (1,000 rpm optional)
Lighting 12 V / 7-pin socket
Electrics 12 V, 20 A socket
Hydraulic systems Open-centre, closed-centre, load-sensing
Minimum pressure 180 bar (2,610 psi)
Minimum flow rate 30 l/min (7.9 gal/min) @ 180 bar (2,610 psi)
