McHale V Series Baler
88
Check that the area around the wheels and especially the brake hubs are
clear of build-up of crop material.
The pick-up guide wheels must be fixed in the road transport position and the
drawbar/PTO stands secured in a working position. (See ‘Drawbar & PTO
shaft stand usage’)
Pick-up wheels in the transport position
8.2 ‘Break-away’ brake (if fitted)
The machine hand brake (if fitted) must be applied when the machine is detached from
the tractor. The hand brake handle has a rope fitted to a calibrated ring which must
have the other end securely fixed to the tractor, each time the machine is attached to
the tractor. If the machine hitch ever becomes detached from the tractor this rope will
apply the brakes on the machine.
CAUTION: Ensure the hand brake is released when moving
Always ensure that the hand brake has been released before moving the
machine on the road or operating in a field.
Break-away rope fixed to tractor Hand brake handle
