McHale V Series Baler
69
7.1 Control box functions
*Functionality in relation to chopper unit knives applies only to models with chopper units!
No. Function
Manual (MAN) Automatic (AUTO)
1
Multi function
2
Multi function
3
Multi function
4
Information button. Press to toggle between the displayed information on the
right of the screen (bale total, density, target diameter, voltage, net layers,
knife pressure, live bale diameter and net stretch).
5
Net feed Press once to start netting bale early.
Hold to delay net feeding.
Press to feed net after a net error.
6
Cut net Cut net after a net error
7
Floor diverter
8
Knife diverter (Machines with chopper unit knives only)*
9
Release density pressure
10
No function
11
No function
12
No function
13
AUTO/MAN button.
Press to switch between manual and automatic modes.
Press and hold to switch to SEMI mode.
14
Menu button.
Press once to enter the machine menu.
Also used to do a factory reset on the control box by holding down and
switching on the power to the box.
15
Emergency stop button.
Press to turn off the box.
Twist clockwise to turn on.
