McHale V Series Baler
58
After this, replace the oil once per season or once per 10,000 bales, whichever comes
first.
6.5 Tyre inflation pressures
Gearbox 1,000 rpm
1. Remove the filler plug (A) using a
24 mm spanner, followed by drain
plug (B) using a 12 mm Allen key.
Drain the oil into a suitable container.
This is best carried out while the oil is
still warm, i.e. soon after use.
Replace the drain plug (B), tighten
securely and dispose of waste oil
responsibly.
2. Add 3 litres of SAE 80W/90 grade oil,
or until oil becomes visible at the
sight glass (C).
3. Replace the filler plug (A) and tighten
securely.
NOTE: Do not overfill the oil
Do not overfill the oil, as this will result in overheating and oil leakage.
Overheating oil can also lead to reduced lubrication properties
CAUTION: Check the tyre pressure weekly
Check the tyres weekly for the pressures outlined in the following table.
Details Type
Field
pressure
Road
pressure
Part No.
460/65-20 155 A8 (Vredestein) Flo + 1.5 bar 2.8 bar CWH00083
500/50-22.5 158 A8 (BKT) 648 1.5 bar 3bar CWH00058
560/45 R22.5 152 D (Alliance) 885 1.5 bar 4bar CWH00092
170/60-8 71 A8 (Vredestein) Pick-up 2.07 bar 2.07 bar CWH00037
