Page 101 Speed Level Series - Service & Parts Manual
January 2019Section 8 - Troubleshooting - 3084RT Models
Selection ID EZ-Cal Readout Explanation
Sub Menu
2A-15a Level / Off Level Status of axle position as read by GP400 - Not used on all models
2A-15b Locked Y/N
Status of oscillating axle lock valves, locked = no oscillation - Not
used on all models
2A-15c Angle
Position of oscillating Axle relative to the chassis - Not used on all
models
2B
PLATFORM
2B-1 Trigger ON/OFF Current status of enable trigger - upper controls
2B-2 DLD Status of Lift/Drive selector switch
2B-3 Joystick
Indicates % of stroke from center in real time. Direction not
indicated here
2B-4
FWD/DWN OFF/
ON
Status of Forward micro-switch Forward stroke of the joystick
2B-5 REV/UP OFF/ON Status of Reverse micro-switch Reverse stroke of the joystick
2B-6 LEFT OFF/ON Status of Left Steer switch
2B-7 RIGHT OFF/ON Status of Right Steer switch
2B-8 Positrac Y/N
Status of rear wheel solenoids activation. Activated in high speed or
elevated drive
2B-9 EMSG OFF/ON Not used
2C
GROUND
2C-1 UP OFF/ON Status of Up switch from lower control station
2C-2 DOWN OFF/ON Status of Down switch from lower control station
2C-3 OUT OFF/ON Not used
2C-4 IN OFF/ON Not used
2C-5 EMSg OFF/ON Not used
2D
INPUTS
2D-1 P7-1 12 Volt Supply. Battery voltage from TBM Module
2D-2 P7-2 Base Selected. ON= Base/Platform select switch in Base position
2D-3 P7-3 Up. On= platform UP switch activated to elevate platform
2D-4 P7-4
Platform Selected. ON= Base/Platform selector switch in Platform
position.
2D-5 P7-5
Limit Switch. ON= limit switch closed - platform low enough to be in
stowed position
2D-6 P7-7 Down. ON= Down switch activated for platform lower operation
2D-7 P79 Throttle Solenoid. ON= Throttle requested by function operation
2D-8 P7-10
Choke (gas engine) or pre-heat (diesel). ON= Choke or Pre-heat
switch activated
2D-9 P7-11
Axle Center Switch. ON= Front axle parallel with chassis - Elevated
drive enabled
2D-10 P7-12 Start. ON= input from engine-start switch
2D-11 P7-13 Oil Pressure Switch
2E
ANALOGS
Not used Not used
