Mec Speed Level Series User Manual

Page 135 Speed Level Series - Service & Parts Manual
January 2019Section 9 - Troubleshooting - 3084ES Models
EZ-Cal Setup
Refer to “EZ-Cal Scan Tool” on page 127.
Operation ID Personality Factory Setting Explanation
6A
CHANGE
DEFAULTS
6A-1 Customer 5=xx84ES Choose basic model and power source
6A-2 Model Select
3 = 3084ES ANSI
4 = 3084ES CE
Choose model and certification
6D
TILT SETUPS
6B-1 Calibrate Level? Y = ENTER N = ESC Follow instructions in Section 7 - Level Sensor Calibration
WARNING! Refer to Tilt Sensor Calibration instructions before attempting calibration
6B-2 Tilt Shutdown 0 = Never Function shutdown tilted when platform stowed
6B-3 Elev Tilt Shutdown 1 = Lift & Drive Function shutdown tilted when platform elevated
6B-4 Axle Tilt 3.0 deg Oscillating axle maximum interlock angle
6C
HEIGHT SETUP
6C-1 Elevation @ 15%
% of maximum height when system goes into elevated
mode
6C-2 Calibrate Height Start Calibration See Section 7 for calibration of Height Sensor
6C-3 Min Lift 1.0 sec Calibration setting - do not change
6C-4 Samples 0.30 sec Calibration setting - do not change
6C-5 Tilt Correction 3=Y+ Calibration setting - do not change
6C-6 Slow Down 10% Calibration setting - do not change
6D
LOAD SETUPS
(EUROPEAN
OPTION ONLY)
6D-1 Calibrate Load Start Calibration See Section 7 for calibration of CE Overload System
6D-2 Faulty Load -100% Calibration setting - do not change
6D-3 Dynamic Scale 110% Calibration setting - do not change
6E
INTERLOCKS
6E-1 Trigger Only 10.0 sec
Time that the enable bar can be held without operation
before timeout
6E-2 Trigger Wait 0.0 sec Delay before function after enable bar is actuated
6E-3 Function hold 0.2 sec Function enabled after operator release
6E-4 Throttle Delay 0.0 sec Delay before throttle enabled (not used)
6E-5 Starter Delay 10.0 sec Starter over-crank feature; time starter is off (not used)
