Page 15 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
Lift And Support The Machine
DEATH OR SERIOUS PERSONAL INJURY MAY RESULT FROM THE USE
OF SUBSTANDARD LIFTING DEVICES AND/OR JACK STANDS. ENSURE
THAT ALL LIFTING DEVICES AND JACK STANDS ARE OF ADEQUATE
CAPACITY AND IN GOOD WORKING CONDITION BEFORE USE.
The following are needed to safely lift and support the machine;
A jack with a lifting capacity of two (2) tons or more.
Jack stands with a rating of two (2) tons or more.
To Raise The Machine
Move machine to a firm level surface capable of supporting the weight of the machine.
Chock tires on one end of machine and raise the other end of machine.
If wheel is to be removed, break loose but do not remove lug nuts before raising the machine.
Position a jack at the end of the machine to be lifted, under a solid lifting point in the center of
the frame.
Raise the machine and place two (2) suitable jack stands under solid support points at the outer
ends of the frame.
Lower the machine to rest on the jack stands and inspect for stability.
To Lower The Machine
Tighten lugs to proper torque (refer to machine specifications).
Raise machine slightly and remove jack stands.
Lower the machine and remove the jack.
Remove chocks.
•
•
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.
