Page 22 Speed Level Series - Service & Parts Manual
January 2019Section 5 - Hydraulic System
Hydraulic Pump Seals - 3084RT
Drive Shaft Seal Replacement
Be careful not to damage the drive shaft when removing the old seal.
Remove the shaft key.
Remove the snap ring.
Remove the shaft seal.
Check the surface of the shaft and the housing for imperfections.
Install new shaft seal.
Cover the keyway portion of the drive shaft with tape to prevent damage to the seal during
installation.
Coat the shaft seal with grease.
Seat the shaft seal with a seal setting tool.
Install the snap ring.
Install the shaft key.
Hydraulic Pump Rebuild
Pump rebuild should be performed only by a qualified mechanic. Contact MEC Technical Support
before attempting to rebuild the pump.
1.
2.
3.
•
4.
•
•
•
5.
6.
