Page 204 Speed Level Series - Service & Parts Manual

January 2019Section 12 - Platform and Rails

Item Part Number Description Qty.

1 83083 Boom Assembly REF

83080 / 83160 Platform Assembly, 3084 REF

83097 Platform Assembly, 2684 REF

19258 Ladder, Side-Bolted 1

19148 Ladder, Top-Bolted 1

4 50040 Bolt, M12 x 35, GR8.8 10

5 50003 Washer, 13.5 mm ID x 24mm OD 14

6 50054 Nut, M12, GR8.8 14

7 50039 Bolt, M12 x 30 4

REF - Reference
