January 2019Section 3 - Specifications
ES Models Specifications
2684ES 3084ES
Working Height* 32 ft* 10.0 m* 36 ft* 11.0 m*
Platform Height 26 ft 7.9 m 30 ft 9.0 m
Stowed Height Rails Up 107 in 2.72 m 105 in 2.67 m
Rails Folded Down 72 in 1.83 m 70 in 1.78 m
Maximum Occupants 0 m/s wind 5 5
45 km/h (12.5 m/s) wind 5 5
On Slide-Out Extension 2 N/A
Lift Capacity 1700 lbs 770 kg 1500 lbs 680 kg
Slide-Out Deck Capacity 700 lbs 320 kg N/A
Platform Dimensions Length (Inside Rails) 12 ft 2 in 3.71 m 14 ft 4.27 m
Length (Platform Extended) 16 ft 2 in 4.93 m N/A
Platform Width (Inside Rails) 72 in 1.83 m 72 in 1.83 m
Guardrail Height 43.5 in 1.1 m 43.5 in 1.1 m
Toeboard Height 6 in 15 cm 6 in 15 cm
Overall Length 13 ft 2 in 4.0 m 14 ft 6 in 4.4 m
Overall Width 84 in 2.13 m
Wheel Base 100 in 2.54 m
Wheel Track 72 in 1.83 m
Turning Radius Inside 8 ft 2.44 m
Outside 16 ft 8 in 5.08 m
Ground Clearance 10 in 25 cm
Machine Weight** (Unloaded) (Approximate) 8400 lb** 3810 kg** 8700 lb** 3946 kg**
Drive System (Proportional)
Drive Speed - Platform Elevated 0-.4 mph 0-.6 km/h
Drive Speed - Platform Lowered 0-3.2 mph 0-5 km/h
Lift/Lower Speeds (Approximate) 35 sec/40 sec
Gradeability 40% 22°
Ground Pressure/Wheel (Maximum) 98 psi 6.9 kg/cm
2
101 psi 7.1 kg/cm
2
Wheel Load 3065 lb 1390 kg 3175 lb 1440 kg
Wind Speed (Maximum) 28 mph 45 km/h (12.5 m/s)
Tire Size - Standard 26 x 12D / 380NHS
Tire Pressure
45 psi 3.1 bar
Foam-filled tires are standard in Europe and Australia, optional in North America
Wheel Lug Nut Torque 75-85 ft/lb 102-115 Nm
Hydraulic Pressure Main System
2800 psi 193 bar
Lift System 2800 psi 193 bar
Steering System 2000 psi 138 bar
Hydraulic Fluid Capacity 23 gallon 87 liters
Electric Motor 8 hp (6kW): 3600 rpm
Power Source -- Voltage 48 volts DC
Batteries Eight 6-volt DC 370 amp-hour industrial deep cycle batteries
Battery Charger Input 120 Volt AC, 50.60 Hz, 18 Amp - 240 Volt AC, 50.60 Hz, 9 Amp
Output 48 Volt DC, 32 Amp, 1500 W, Timed Shutoff
Maximum Vibration Does not exceed 2.5 m/sec at operator’s position
Ambient Operating Range -30° C minimum; 50° C maximum
Operating Inclination Manual and self-leveling, side/side to 14°, fore/aft to 10°
Brakes Dual Rear Wheel Multi-disc
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options or country standards.
