Page 97 Speed Level Series - Service & Parts Manual
January 2019Section 8 - Troubleshooting - 3084RT Models
EZ-Cal Adjustment
Refer to “Using the EZ-Cal Scan Tool” on page 91.
Adjustments possible in Access Level 1 Only.
Before changing personalities, ensure that the correct customer and model have been selected in the
SETUPS menu. Any changes to settings will be lost when the model or customer is changed.
To reach ADJUSTMENTS, first access Level 1, then press --> for ADJUSTMENTS. Press Enter, then
press --> to scroll through the sub-menus.
Once the desired sub-menu is found, press Enter again, then --> to scroll through the personalities.
Press the Up or Down arrows to change the personality. Press ESC to go back one or more levels to
reach other sub-menus.
Operation ID Personality Factory Setting Explanation
5A
DRIVE
(PLATFORM
STOWED)
5A-1 FWD Min 33% Slowest speed possible
5A-2 FWD Max 100% Maximum speed potential
5A-3 REV Min 31% Slowest speed possible
5A-4 REV Max 100% Maximum speed potential
5A-5 ACCEL 1.8 sec Ramp-up time to maximum
5A-6 DECEL 1.6 sec Ramp-down time to stop
5A-7 MAX Height 101% Maximum drivable height
POSITRACK 5A-8 Positrack - Sub category, press ENTER to access
Sub Menu
5A-8a AUTO below 0% Not Used
5A-8b AUTO Not Used Not Used
5B
DRIVE
ELEVATED
5B-1 FWD Min 33% Slowest speed possible
5B-2 FWD Max 46% Maximum speed potential
5B-3 REV Min 31% Slowest speed possible
5B-4 REV Max 49% Maximum speed potential
5B-5 ACCEL 5.0 sec Ramp-up time to maximum
5B-6 DECEL 5.0 sec Ramp-down time to stop
5C
LIFT
5C-1 UP Min 5% Slowest speed possible
5C-2 UP Max 52% Maximum speed potential
5C-3 DOWN Min 0% (not used) Gravity down (not used)
5C-4 DOWN Max 0% (not used) Gravity down (not used)
5C-5 ACCEL 1.2 sec Ramp-up time to maximum
5C-6 DECEL 0.5 sec Ramp-down time to stop
5C-7 MAX Height ANSI: 101% CE: 98% Maximum height potential
ARMGUARD (CE) 5C-8 Armguard - Sub category, press ENTER to access
Sub Menu
5C-8a Armguard Time 0.0 sec CE Option Only
5C-8b Armguard @ Height 101% CE Option Only
5D
STEER
5D-1 Speed 0% Maximum speed potential
5D-2 Drive Compensation 0%
Adds additional to drive speed
5D-3 Drive Comp Elevated 0% Adds additional to drive speed elevated
5D-4 ACCEL 0.2 sec Ramp-up time to maximum
5D-5 DECEL 0.2 sec Ramp-down time to stop
5E - DECK 5E- Not Used Not Used Power-out deck (not used)
