Mec Speed Level Series User Manual

Page 270 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1
16978 Power Module Weldment, ES 1
16213 Power Module Weldment, RT 1
2
16984 Power Module Door, ES 1
16220 Power Module Door, RT 1
3
16989 Control Module, ES 1
16153 Control Module, RT 1
4
16985 Control Module Door, ES 1
16156 Control Module Door, RT 1
5 8386 Door Latch Trigger 1
6 19106 Module Bracket, Right Front 1
7 19105 Module Bracket, Right Rear 1
8 19104 Module Bracket, Left Rear 1
9 19103 Module Bracket, Left Front 1
10 50039 Bolt, M12 x 30 24
11 50003 Washer, M12 24
12 50050 Nut, M12 Nylock 24
13 19155 Hose Cover, Right Side 1
14 19154 Hose Cover, Left Side 1
15 19159 RT Models -- Exhaust Cover 1
16 90749 Plug, Marinco 15 Amp 1
17 REF
Cable, Power To Platform, 14G -- See “Wire Harness” Page At The End Of Section
16
--
18 19159 Exhaust Shroud
19 50289 HHCS M06-1.00 X 40MM ZP 1
20 50000 Washer M06 ZP Standard Flat 1
21 50047 NNYL M06 X 1.00 08 ZP Nylock 1
