Mec Speed Level Series User Manual

Page 4 Speed Level Series - Service & Parts Manual
January 2019
RT Models Specifications
2684RT 3084RT
Working Height* 32 ft* 10.0 m* 36 ft* 11.0 m*
Platform Height 26 ft 7.9 m 30 ft 9.0 m
Stowed Height Rails Up 107 in 2.72 m 105 in 2.67 m
Rails Folded Down 72 in 1.83 m 70 in 1.78 m
Maximum Occupants 0 m/s wind 5 5
45 km/h (12.5 m/s) wind 5 5
On Slide-Out Extension 2 N/A
Lift Capacity 1700 lbs 770 kg 1500 lbs 680 kg
Slide-Out Deck Capacity 700 lbs 320 kg N/A
Platform Dimensions Length (Inside Rails) 12 ft 2 in 3.71 m 14 ft 4.27 m
Length (Platform Extended) 16 ft 2 in 4.93 m N/A
Platform Width (Inside Rails) 72 in 1.83 m 72 in 1.83 m
Guardrail Height 43.5 in 1.1 m 43.5 in 1.1 m
Toeboard Height 6 in 15 cm 6 in 15 cm
Overall Length 13 ft 2 in 4.0 m 14 ft 6 in 4.4 m
Overall Width 84 in 2.13 m
Wheel Base 100 in 2.54 m
Wheel Track 72 in 1.83 m
Turning Radius Inside 8 ft 2.44 m
Outside 16 ft 8 in 5.08 m
Ground Clearance 10 in 25 cm
Machine Weight** (Unloaded) (Approximate) 7800 lb** 3535 kg** 8100 lb** 3674 kg**
Drive System (Proportional)
Drive Speed - Platform Elevated 0-.4 mph 0-.6 km/h
Drive Speed - Platform Lowered 0-3.2 mph 0-5 km/h
Lift/Lower Speeds (Approximate) 35 sec/40 sec
Gradeability 40% 22°
Ground Pressure/Wheel (Maximum) 90 psi 6.3 kg/cm
2
94 psi 6.6 kg/cm
2
Wheel Load 2855 lb 1295 kg 2965 lb 1345 kg
Wind Speed (Maximum) 28 mph 45 km/h (12.5 m/s)
Tire Size - Standard 26 x 12D / 380NHS
Tire Pressure
45 psi 3.1 bar
Foam-filled tires are standard in Europe and Australia, optional in North America
Wheel Lug Nut Torque 75-85 ft/lb 102-115 Nm
Hydraulic Pressure Main System
2800 psi 193 bar
Lift System 2800 psi 193 bar
Steering System 2000 psi 138 bar
Hydraulic Fluid Capacity 23 gallon 87 liters
Engine
Diesel -- Kubota D1105E, 25HP (18.6 kW), Liquid Cooled Dual Fuel (North America only)
-- Kubota DF752, 20HP (14.9 kW), Liquid Cooled
Noise Level 86 dB maximum
Maximum Vibration Does not exceed 2.5 m/sec at operator’s position
Ambient Operating Range -30° C minimum; 50° C maximum
Operating Inclination Manual and self-leveling, side/side to 14°, fore/aft to 10°
Brakes Dual Rear Wheel Multi-disc
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options or country standards.
RT Models Specifications
Section 3 - Specifications

Mec Speed Level Series Specifications

General

Brand	Mec
Model	Speed Level Series
Category	Boom Lifts
Language	English
