GP400 Control Module Setup
Location
The GP400 Control Module processor is located
in the lower control box.
The GP400 Matrix Module is located in the upper
control box.
Diagnostic information can be found in Section 9 or 10
for Troubleshooting. Wiring information can be found in
Section 11: Schematics.
•
•
ART_3156
GP400
Control Module
GP400
Matrix Module
Diagnostic LED
Lower ControlsUpper Controls
Terminal
Block
Module
