Page 98 Speed Level Series - Service & Parts Manual
January 2019Section 8 - Troubleshooting - 3084RT Models
Operation ID Personality Factory Setting Explanation
5F
OUTRIGGERS
Called “Outriggers”
on the EZ-Cal,
these personalities
effect Auto-level
function
5F-1 Outriggers 2 Not Used
5F-2 Extend 50% O/R speed before all legs down
5F-3 Level 35% O/R speed after all legs touch down
5F-4 Retract 55% Maximum speed potential
5F-5 Debounce 0.35 Compensates for switch bounce
5F-6 Initial 0.5 Not Used
5F-7 Tilt filter 6 Compensates for tilt sensor free movement
5F-8 X Tilt target 0.2 deg Target level stops movement
5F-9 Y Tilt target 0.2 deg Target level stops movement
5F-10 Tilt Slack 0.3 deg Additional compensation
5F-11 Outrigger Test Yes/No Not Used
5G
GROUND MODE
Lower Control
Operations
5G-1 UP 53% Maximum speed potential
5G-2 DOWN 0% Gravity down
5G-3 OUT 0% Power deck operation (not used)
5G-4 IN 0% Power deck operation (not used)
5G-5 ACCEL 1.0 sec Ramp-up time to maximum
5G-6 DECEL 1.0 sec Ramp-down drive output
5H
TILT
5H-1 X Trip 2.0 degrees Angle tilt sensor signals Out Of Level
5H-2 Y Trip 2.0 degrees Angle tilt sensor signals Out Of Level
5H-3 Delay Trip 2.0 sec Time delay between Tip and Signal
5H-4 Delay Clear 0.5 sec Time delay between Tip and Signal OFF
TILT 2 5H-4 Tilt 2 - Sub category, press ENTER to access
Sub Menu
5H-5A At Height 101% Point where lesser tilt angle used
5H-5B X Trip 2 1.5 sec Not Used
5H-5C Y Trip 2 1.5 sec Not Used
5I
OVERLOAD
5I-1 Trip @ ANSI: 0% CE: 110% % of weight over maximum to trigger overload
5I-2 Lamp @ ANSI: 0%
CE: 0% % of weight over maximum to trigger lamp
ANSI: values = 0
5I-3 Alarm @ ANSI: 0% CE: 0% % of weight over maximum to trigger alarm
5I-4 @ Height ANSI: 0% CE: 8% % of elevation load sense starts monitoring weight
CE: values apply 5I-5 Safe Down ANSI: 0% CE: 12% % of elevation lift-down still operates in overload
5I-6 Delay Trip 1.5 sec Delay before overload trip
5I-7 Delay Clear 1.5 sec Delay before overload clear
OVERLOAD 2 5I-8 Overload # 2 - Sub category, press ENTER to access
Sub Menu
5I-8a @ Height 0% % of height for secondary overload valve
5I-8b Scale 100% % of reduced overload valve
5J
ALARMS
5J-1 Drive: Yes/No No 1 = FWD 2 = REV 3 = Both 4 = All Motion
5J-2 Lift 2 = Down 1 = UP 2 = DOWN 3 = Both 4 = All Motion
5J-3 Tilt 1 = When Elevated 1 = When Elevated 2 = Always
5K
HEIGHTS
5K-1 Elevation 15% Point at which machine enters elevated mode
5K-2 Maximum Drive 101% Maximum drivable height
5K-3 Maximum Lift ANSI: 101% CE: 98% Maximum elevated height potential
5K-4 Armguard 101% Stops descent for 5 sec
5K-5 Overload ANSI: 0% CE: 8% % of elevation load sense starts monitoring weight
5K-6 Safe Down ANSI: 0% CE: 12% % of elevation lift-down still operates in overload
5K-7 Overload # 2 0% Not Used
5K-8 Tilt # 2 ANSI: 0% CE: 0% Reduced degree of tilt at % elevation
