Page 99 Speed Level Series - Service & Parts Manual
January 2019Section 8 - Troubleshooting - 3084RT Models
Operation ID Personality Factory Setting Explanation
6A
CHANGE
DEFAULTS
6A-1 Customer 5: XX84RT
Identifies Base Model
Must be set when GP400 is Replaced
6A-2 Model
5 = ANSI
6 = CE
Select from these choices only
6D
TILT SETUPS
6B-1 Calibrate Level? Y = ENTER N = ESC
Follow instructions in Section 7- Level
Sensor Calibration
WARNING! Refer to Tilt Sensor Calibration instructions before attempting calibration
6B-2 Tilt Shutdown 0 = Never
Function shutdown tilted when platform
stowed
6B-3 Elevated Shutdown 1 = Lift & Drive
Function shutdown tilted when platform
elevated
6B-4 Axle Tilt 3.0 deg
Maximum deflection of axle before
elevated drive interlock
6C
HEIGHT SETUP
(CE OPTION
ONLY)
6C-1 Elevation @ 13%
6C-2 Calibrate Height Start Calibration
See Section 7 for calibration of Height
Sensor
6C-3 Minimum Lift 1.0 sec Calibration setting - do not change
6C-4 Samples 0.10 sec Calibration setting - do not change
6C-5 Tilt Correction Disabled Calibration setting - do not change
6C-6 Slow Down 10% Calibration setting - do not change
6D
LOAD SETUPS
(CE OPTION
ONLY)
6D-1 Calibrate Load Start Calibration
See Section 7 for calibration of CE
Overload System
6D-2 Faulty Load 100% Calibration setting - do not change
6D-3 Dynamic Scale 95% Calibration setting - do not change
6D-4 Delay Up 0.0 sec Not Used
6D-5 Delay Down 0.0 sec Not Used
6E
INTERLOCKS
6E-1 Trigger Only 10.0 sec
Enable bar held without operation before
interlock
6E-2 Trigger Wait 0.0 sec
Delay after enable bar pulled before
function enabled
6E-3 Function hold 0.2 sec Function enabled after operator release
Delays 6E-4 Delays - Sub category, press ENTER to access
Sub Menu 6E-4a Throttle Delay 0.0 sec Delay before throttle enabled
6E-4b Start Delay 10.0 sec
Interlocks start to protect start system
from overheat
