Page 162 Speed Level Series - Service & Parts Manual
January 2019
3084RT - Diesel/Dual Fuel Models
Hydraulic - 3084RT
The following table applies to page 163 - 165.
Callout Description
MA-1 MAIN MANIFOLD
CBV1 Counter Balance Valve, Drive
CBV2 Counter Balance Valve, Drive
CL1 Coil - Speed/Torque/Steer Valves #8
CL2 Coil - Lift Valve #10
CV1 Check Valve, Load Sense Steer Left
CV2 Check Valve, Load Sense Steer Right
EC1 Priority Flow Control
EP1 Piloted Poppet Valve - Torque/Speed
EP2 Piloted Poppet Valve - Torque/Speed
FD1 Flow Divider/Combiner
FD2 Flow Divider/Combiner
HP1 Hand Pump, Brake Release
LS1 Load Sense Shuttle Valve
LS2 Load Sense Shuttle Valve
LS3 Load Sense Shuttle Valve
MP1 Manual Push Brake Release Valve
OD1 Orifice Disc, Brakes, 0.035
OPL1 Orifice Plug, Steering, 0.087
OPL2 Orifice Plug, Flow Divider Bleed, 0.025
OPL3 Orifice Plug, Flow Divider Bleed, 0.025
ORF1 Orifice, Steering, 0.064
ORF2 Orifice, Lift, 0.093
PD1 Pilot Valve, Series Parallel, 4-Way / 3-Position
PD2 Pilot Valve, Series Parallel, 4-Way / 3-Position
PD3 Pilot Valve, Series Parallel, 4-Way / 3-Position
PLG4 Port Plug
PLG6 Port Plug
RV1 Relief Valve, Lift, 2500 PSI
RV2 Relief Valve, Steering, 2000 PSI
SP1 Proportional Valve
SV1 Spool Valve, Lift, 3-Way
SV2 Spool Valve, Steer, 4-Way / 3-Position
SV3 Spool Valve, Series Parallel, 4-Way / 3-Position
SV4 Spool Valve, Series Parallel, 4-Way / 3-Position
SVD1 Spool Valve, Drive, 4-Way / 3-Position
Callout Description
STEERING COMPONENTS
CYL1 Steer Cylinder, Right
CYL2 Steer Cylinder, Left
TILT COMPONENTS
MA-2 Combination Valve Manifold - Tilt
CV3 Check Valve, Tilt, Side/Side Load Sense
CV4 Check Valve, Tilt, Front/Rear Load Sense
CV5 Check Valve, 10 PSI Oscillating axle
CV6 Check Valve, Tilt Cyl, Front/Rear
CV7 Check Valve, Tilt Cyl, Front/Rear
CV8 Check Valve, Tilt Cyl, Side/Side
CV9 Check Valve, Tilt Cyl, Side/Side
CYL4 Tilt Cylinder, Front/Rear
CYL5 Tilt Cylinder, Side/Side
CYL6 Axle Lock Cylinder
CYL7 Axle Lock Cylinder
ORF4 Orifice, 0.040, Tilt, Side/Side
ORF5 Orifice, 0.040, Tilt, Front/Rear
RV3 Relief Valve, Tilt Cyl Front/Rear, 2500 PSI
RV4 Relief Valve, Tilt Cyl Front/Rear, 2500 PSI
RV5 Relief Valve, Tilt Cyl Side/Side, 2500 PSI
RV6 Relief Valve, Tilt Cyl Side/Side, 2500 PSI
SV8 Spool Valve, Tilt Front/Rear
SV9 Spool Valve, Tilt Side/Side
LIFT COMPONENTS
MA-3 Lift Cylinder Manifold
CYL3 Lift Cylinder
ORF3 Orifice, 0.067 Descend
SV5 Solenoid Valve, 12V, Dual Coil
Wheel Motors
LF Wheel Motor - Left Front
LR Wheel Motor w/ Brake - Left Rear
RF Wheel Motor - Right Front
RR Wheel Motor w/ Brake - Right Rear
SV6 Spool Valve - Right Wheel Motor Bypass
SV7 Spool Valve - Left Wheel Motor Bypass
RESERVOIR
FL1 Filter, 10 Micron, Fluid Return
P1 Pump, Hydraulic Fluid
3084RT - Diesel/Dual Fuel Models
Section 10 - Schematics
