Page 188 Speed Level Series - Service & Parts Manual
January 2019Section 11 - Controls
Item Part Number Description Qty.
Fixed Control Box Assembly
1
83169 Assy, Upper Control Box, Without Options - 3084 ANSI ES 1
83170 Assy, Upper Control Box, With Horn Option - 3084 ANSI ES 1
83171 Assy, Upper Control Box, Without Options - 3084 ANSI DSL 1
83172 Assy, Upper Control Box, With Horn Option - 3084 ANSI DSL 1
83189 Assy, Upper Control Box, Without Options - 3084 CE ES 1
83190 Assy, Upper Control Box, With Horn Option - 3084 CE ES 1
83191 Assy, Upper Control Box, Without Options - 3084 CE DSL 1
83192 Assy, Upper Control Box, With Horn Option - 3084 CE DSL 1
2 REF Strain Relief Washer (See Wire Harness, Section 6) 1
3 REF Mounting Plate (See Wire Harness, Section 6) 1
4 REF Cable, Fixed (See Wire Harness, Section 6) 1
Removable Control Box Assembly
5
83064 Assembly With Removable Cable, ES Models 1
83065 Assembly With Removable Cable, RT Models 1
6 REF Harness, Removable (See Wire Harness, Section 6) 1
7 REF Cable, Removable (See Wire Harness, Section 6) 1
All Models
8 16242 Weldment, Control Box 1
9 13865 Bracket, Control Box Holder 1
10 6350 Tape, Foam .5 ft
11 50109 Screw, 5/16–18 1
12 13864 Bracket, Control Box Holder 1
13 50063 Washer, Flat 1
14 8826 Thumb Screw, 5/16–18, Flower 1
15
6234 Switch, Toggle, Lift/Drive 1
6234 Switch, Toggle, Generator Option 1
16
9184 Lens, Amber, Tilt Indicator 1
9188 Light, Bayonet, 14 Volt 1
9179 Socket, Indicator Light 1
17 6905 Switch, Toggle, Speed/Torque 1
18 7800 Switch, Emergency Stop 1
19 RT 91619 RT Models - Switch, Start 1
19 ES
91926 ES Models - Switch, Start 1
90714 ES Models - Switch Base 1
8082 ES Models - Contact Block, N.O. 1
20 7423 Switch Toggle 1 Pole 2 Position 3 1
21
8044 Switch, Button (Horn Option) 1
8819 Boot 1
22
-- -- --
23 91954 Switch, 3-Position Momentary 2
24 -- -- --
25 91663 Matrix Module 1
26 50189 Screw, 10-32 x 1.25 2
27 50238 Nut, 10-32 Nylock 2
REF - Reference
To Next Page
