Page 190 Speed Level Series - Service & Parts Manual
January 2019Section 11 - Controls
Item Part Number Description Qty.
Removable Control Box Assembly
1
83169 Assy, Upper Control Box, Without Options - 3084 ANSI ES 1
83170 Assy, Upper Control Box, With Horn Option - 3084 ANSI ES 1
83171 Assy, Upper Control Box, Without Options - 3084 ANSI DSL 1
83172 Assy, Upper Control Box, With Horn Option - 3084 ANSI DSL 1
83189 Assy, Upper Control Box, Without Options - 3084 CE ES 1
83190 Assy, Upper Control Box, With Horn Option - 3084 CE ES 1
83191 Assy, Upper Control Box, Without Options - 3084 CE DSL 1
83192 Assy, Upper Control Box, With Horn Option - 3084 CE DSL 1
2 REF Harness, Removable (See Wire Harness, Section 6) 1
3 REF Cable, Removable (See Wire Harness, Section 6) 1
4 16242 Weldment, Control Box 1
5 13865 Bracket, Control Box Holder 1
6 6350 Tape, Foam .5 ft
7 50109 Screw, 5/16–18 1
8 13864 Bracket, Control Box Holder 1
9 50063 Washer, Flat 1
10 8826 Thumb Screw, 5/16–18, Flower 1
11
9183 Lens, Red, Overload 1
9188 Light, Bayonet, 14 Volt 1
9179 Socket, Indicator Light 1
12 7553 Alarm 1
13
6234 Switch, Toggle, Lift/Drive 1
6234 Switch, Toggle, Generator Option 1
14 6905 Switch, Toggle, Speed/Torque 1
15 7800 Switch, Emergency Stop 1
16 RT 91619 RT Models - Switch, Start 1
16 ES
91926 ES Models - Switch, Start 1
90714 ES Models - Switch Base 1
8082 ES Models - Contact Block, N.O. 1
17 7423 Switch Toggle 1 Pole 2 Position 3 1
18 -- -- --
19 8044 Switch, Button (Horn Option) 1
20 7423 Switch Toggle 1 Pole 2 Position 3 1
21 5694 Switch, Toggle, Manual Level, Front-Rear 1
22 91954 Switch, 3-Position Momentary 2
23 91663 Matrix Module 1
24
50189 Screw, 10-32 x 1.25 2
25 50238 Nut, 10-32 Nylock 2
REF - Reference
