Page 194 Speed Level Series - Service & Parts Manual

January 2019Section 11 - Controls

Item Part Number Description Qty.

-- 92199 Joystick Assembly --

-- 8630 Joystick Assembly Without Control Arm (#6) --

1 8750 Pin (Service Only) 1

2 8453 Switch Actuator (Service Only) 1

3 HDW8455 Screw (Service Only) 4

4 8752 Grip, Top Half (Service Only) 1

5 8751 Grip, Bottom Half (Service Only) 1

6 13638 Control Arm Without Wire 1

7 8748 Trigger (Service Only) 1

8 8456 Rocker Boot (Service Only) 1

9 8447 Switch Separator (Service Only) 1

10 8753 Motion Switch, OFF-ON (Service Only) 1

11 8448 Switch (Service Only) 2

12 91839 Amp Socket (Not Shown) 3

13 92194 Push Connector, 3/16” 1

-- 8761

Switch Assembly (Not Shown) -- Includes Item #9, Item #11 (x2), Wire And

Connectors
