Page 202 Speed Level Series - Service & Parts Manual
January 2019Section 11 - Controls
Item Part Number Description Qty.
-- 83079 Lower Control Box Assembly, Diesel Models 1
1 9549 Switch, 3-Position, Keyed 1
2 91667 Switch, Button, Green 3
3 91957 Switch, Button, Black 1
4 7800 Switch, Emergency Stop 1
-- -- -- --
6 91704 Hour Meter 1
7 92254 Light, Red 1
8 7235 Circuit Breaker 1
9 7423 Switch Toggle 1 Pole 2 Position 3 1
-- -- -- --
11 8082 Contact Block, N. O. 6
12 91711 Alarm, 107dB 1
13 17082 Bracket, Alarm Mount 1
14 91838 Terminal Block Module (TBM) 1
15 91659 System Controller, GP400 1
16 91887 Deutsch Connector, DRC 12 70P 1
17 90714 Contact Base 6
18 1313 Switch Guard 1
19 91290 Deutsch Connection, DT14-4P-L012 1
20 50229 Screw, 10-24 x 1.00 6
21 50230 Nut, 10-24 Nylock 6
22 50233 Screw, 8-32 x 1.00 6
23 50231 Nut, 8-32 Nylock 6
24 91921 Lanyard 1
25 92016C Control Box 1
-- REF Harness -- See Section 6 --
REF - Reference
