Mec Speed Level Series User Manual

Page 208 Speed Level Series - Service & Parts Manual
January 2019Section 12 - Platform and Rails
Item Part Number Description Qty.
1 50000 WSHR M06 ZP Standard Flat 60
2 50002 WSHR M10 ZP Standard Flat 7
3 50020 HHCS M10-1.50x050 08 ZP P 3
4 50021 HHCS M10-1.50x055 08 ZP P 2
5 50296 HHCS M06-1.00x16 08 ZP P 4
6 50047 NNYL M06x1.00 08 ZP Nylock 60
7 50049 NNYL M10x1.50 08 ZP Nylon Inse 5
8 50262 HHCS M06-1.00x050 08 ZP F 56
9 19109 Deck Weldment 1
10 91888 Gate Hinge 2
11 84148 Reinforcement Rail Corner Assy 2
12
83165 Front Right Rail Assy 1
19141 Front Right Rail Only 1
13
83164 Front Left Rail Assy 1
19136 Front Left Rail Only 1
14
83161 Platform Side Rail Assy 2
19116 Platform Side Rail Only 1
15
83153 Main Deck Right Rail Assy 1
19384 Main Deck Right Rail Only 1
16
83152 Main Deck Left Rear Rail Assy 1
19381 Main Deck Left Rear Rail Only 1
17
83149 Entry Gate Weldment 1
22366 Entry Gate Only 1
18 19376 Deck Gate Lock 1
19 19263 Diamond Plate Decking 1
20 19239 Hinge Spacer 4
21 19133 Weldment, Loading Gate 1
22 8909 Enclosure Service Manual 1
23 6823 Cap Plug 1-1/4” Sq. Tube 10
24 91024 Hinge 1
