Page 210 Speed Level Series - Service & Parts Manual
January 2019Section 12 - Platform and Rails
Item Part Number Description Qty.
-- 83097 Platform Assembly, 2684 1
1 19356 Platform Weldment 1
2 19377 Side Rail 4
3 19381 End Rail, Left 1
4 22366 Gate Weldment 1
-- 22372 Gate Toeboard 1
-- 16799 Gate Latch (Not Shown) 1
-- 7408 Gate Latch (Not Shown) 1
-- 50015 Bolt, 8 x 50 (Not Shown) 1
-- 50001 Washer, #8 (Not Shown) 2
-- 50048 Nut, #8 Nylock (Not Shown) 1
5 19384 End Rail, Right 1
6 91888 Hinge 2
7 50125 Bolt, 6mm x 55 8
8 50000 Washer, M6 Flat 8
9 50047 Nut, M6 Nylock 8
10 19239 Backing Plate, Hinge 4
11 50039 Screw, M12x1.75 x 30 10
12 91593 Bearing 10
13 19399 Roller 2
14 19398 Axle, Threaded 2
15 19131 Rail Wheel 64
16 50016 Bolt, M8 x 55 32
17 50001 Washer, M8 64
18 50048 Nut, M8 Nylock 32
19 50283 Bolt, M4 x 55 16
20 50284 Washer, M4 32
21 50285 Nut, M4 Nylock 16
22 19390 Platform Deck Plate 1
23
84148 Reinforcement Rail Corner Assy 1
22459 Plate, Corner Cap 2
22458 Pin, Corner Cap 4
50286 Bolt, Button Head, M12 x 50 4
Items #24 and #25 used on serial numbers 12800001 - 12800009 only
24 22248 Block, Deck Extension Stop 2
25
50036 Bolt, M10-1.5 x 50 4
50006 Washer, M10 Nordlock 4
