Mec Speed Level Series User Manual

Page 212 Speed Level Series - Service & Parts Manual
January 2019Section 12 - Platform and Rails
Item Part Number Description Qty.
-- 83097 Platform Assembly, 2684 1
11 Screw, Countersink 10
12 91593 Bearing 10
13 19399 Roller 2
14 19398 Axle, Threaded 2
15 19131 Rail Wheel 64
16 50016 Bolt, M8 x 55 32
17 50001 Washer, M8 64
18 50048 Nut, M8 Nylock 32
19 50283 Bolt, M4 x 55 16
20 50284 Washer, M4 32
21 50285 Nut, M4 Nylock 16
26 19337 Platform Extension Weldment 1
27 19424 Side Rail, Deck Extension, Right Side 1
28 19432 Side Rail, Deck Extension, Left Side 1
29 92219 Spring Pin, M8 x 55 1
30 19367 Deck Extension Handle Weldment 1
31 19370 Deck Extension Bar 1
32 19374 Gate, Material Loading 1
33 8909 Manuals Case 1
34 19376 Latch, Material Loading Gate 1
35 50015 Bolt, M8 x 50 11
36 50001 Washer, M8 20
37 50048 Nut, M8 Nylock 7
38 50028 Bolt, M6 x 20 4
39 50000 Washer, M6 8
40 50047 Nut, M6 4
41 50287 Bolt, Button Head Cap Screw, M8 x 70 2
42 -- -- --
43 -- -- --
44 -- -- --
45 -- -- --
46 50288 Cap Screw, Shouldered, M10 x 60 2
47 50053 Nut, M10
2
48 19389 Plate 1
49 92218 Spring 2
50 19385 Weldment, Locking Rack 1
51 19388 Locking Track 2
52 19391 Platform Extension Deck Plate 1
53 16791 Threaded Axle 3
54 16793 V-Wheel 2
55 16792 Flat Wheel 1
