Page 214 Speed Level Series - Service & Parts Manual

January 2019Section 13 - Boom

Item Part Number Description Qty.

-- 83081 Chassis Assembly 1

1 19020 Chassis Weldment 1

2 19031 Boom Mount Weldment 1

3 19013 Level Pivot Weldment 1

4 19124 Pin 2

5 19123 Pin 1

6 18152 Pin Retainer 1

7 50023 Bolt, M12 x 50 6

8 19122 Pin 4

9 50119 Nut, Nylock 1-1/4” 8

10 19081 Cylinder, Level 2

11 50039 Bolt, M12 x 30 1

12 92011 Bearing, Flange 4

13 50007 Washer, M12 Nord-Lock 6

14 50065 Flat Washer, 1¼ 8

15 19164 Spacer 8

16 92201* CAN Tilt Angle Transducer, Model 151 1

17 50125 Screw, M6 x 55 2

18 50047 Nut, M6 Nylock 2

19 50068 Washer, M6 Fender 2

20 92040 Spacer As Needed

* For adapter from early style (1-Plug) CAN Tilt to new style (2-Plug) CAN Tilt use 22538
